Medical Power Supplies

Red Cross Button

Medical Safety Certified, Single Output Power Supplies

MED PS Series - for 'non-patient contact' applications are MOOP Level Certified

(See the RPS Series below for "patient contact" appoved supplies.)

Suitable applications include medical and diagnostic equipment requiring low leakage current, chemical or biological detection equipment, medical measurement and medically related analytical equipment, and any apparatus or system requiring low, no-load power consumption.



MED-PS Series Features at a Glance:

Medical safety certified, MOOP level

High efficiency (up to 89%)

Built-in active PFC function, PF > 0.95

Withstands 300VAC surge for 5 seconds

Low leakage current

No-load power consumption < 0.6W

Standby 5V @ 0.3A

Protection: Short circuit/Overload/Over voltage/Over temperature (optional on 100 series)

Built-in: Constant current limiting circuit

Built-in: Remote sense function

Built-in: Remote ON-OFF control

Built-in DC OK signal

Simple (-5% ~ +10%) voltage adjustment by easy to reach rheostat on terminal strip

105ºC long-life electrolytic capacitors

Certificates: UL / CUL / CB / CE

Safety standards: ANSI/AAMI ES60601-1, IEC60601-1 approved

EMC standards: Class B Level

Comply with RoHS 2011/65/EU and PFOS 2006/122/EC (PerFluoroOctane Sulfonates)

5 year warranty



MED RPS Series - approved for "patient contact" equipment (MOPP Level Certified)

For medical applications that require both miniature size and MOPP certification. These are 5” x 3” compact PCB-type power supplies have full range AC Input (90~264VAC) for use worldwide.



MED-RPS Series Features at a Glance:

Medical safety approved (2 x MOPP between primary to secondary) “patient contact” compliant

5” x 3” compact size and high power density (14.5W/in3)

High efficiency (up to 93%)

Low leakage current of ≦300μA at 264VAC

Built-in active PFC function, PF > 0.95

90~264VAC full range input for use worldwide

Withstand 300VAC input surge for 5 seconds

No-load power consumption < 0.5W allowing use in “green mode” medical equipment

Built-in 12V/ 0.5A auxiliary output (generally for fan) and 5V/1A standby output

Protection: Short circuit / Overload / Over voltage / Over temperature

Built-in remote sense function and remote ON/OFF control

Power good (P.G.) and fail (P.F.) signal output

Working temperature from -30ºC ~ +70ºC (-22°F~158°F)

Certificates: UL / CUL / TUV / CB / CE

Medical certificates per ANSI/AAMI ES60601-1, TUV EN60601-1, and CE

EMC standards: Class B Level

Comply with RoHS 2011/65/EU and PFOS 2006/122/EC (PerFluoroOctane Sulfonates)

3 year warranty

Comply with ROHS (Restriction of Hazardous Substances) and 2006/122/EC - PFOS (PerFluoroOctane Sulfonates)

Purchasing agents and other quantity buyers are encouraged to request a quotation.
